VAND PLACA DE BAZA M810LR

PLACA DE BAZA M810LR:
Socket-462 Processor Support
¨ Supports AMD Athlon XP/Athlon/Duron processors
¨ Supports 200/266 MHz Front-Side Bus

Processors are automatically configured using firmware and a synchronous Host/DRAM Clock Scheme.

Memory Support
¨ Two DIMM slots for 168-pin SDRAM memory modules
¨ Support for 100/133 MHz memory bus
¨ Maximum installed memory is 2 x 512MB = 1GB

Expansion Slots
¨ One AMR slot for a special audio/modem riser card
¨ One optional AGP4X slot for AGP 2.0-compliant interface
¨ Two 32-bit PCI slots for PCI 2.2-compliant bus interface.

Onboard IDE channels
¨ Primary and Secondary PCI IDE channels
¨ Support for PIO (programmable input/output) modes
¨ Support for Multiword DMA modes
¨ Support for Bus Mastering and Ultra DMA 33/66/100 modes

Power Supply and Power Management
¨ ATX power supply connector
¨ ACPI and previous PMU support, suspend switch, keyboard power on/off
¨ Supports Wake on Modem, Wake on LAN and Wake on Alarm

Built-in Graphics System
¨ Onboard 128-bit 2D/3D 100MHz Host interface AGP Graphics Accelerator Complies with AGP V2.0
¨ Shared memory architecture allows a maximum of 64 MB main memory to act as frame buffer
¨ Supports high resolutions up to 1920x1440 Hi-colors, up to 2048x2048 Texture size and Virtual screen up to 4096x4096
¨ Supports hardware dvd Accelerator

AC’97 Codec
¨ Intel AC’97 v2.2 specification compatible
¨ Supports 16-bit ADC and DAC as well as stereo full-duplex codec
¨ Supports 4 channel DAC for 4 channel speaker-out

Onboard I/O Ports
¨ Provides PC99 Color Connectors for easy peripheral device connections
¨ Floppy disk drive connector with 1Mb/s transfer rate
¨ One serial port with 16550-compatible fast UART
¨ One parallel port with ECP and EPP support
¨ Two USB ports and optional two USB ports module
¨ Two PS/2 ports for keyboard and mouse
¨ One infrared port connector for optional module

Hardware Monitoring
¨ Built-in hardware monitoring for CPU & System temperatures, fan speeds and mainboard voltages

Built-in Ethernet LAN
¨ Built-in 10BaseT/100BaseTX Ethernet LAN
¨ LAN controller integrates Fast Ethernet MAC and PHY compliant with IEEE802.3u 100BASE-TX, 10BASE-T and ANSI X3.263 TP-PMD standards
¨ Compliant with ACPI 1.0 and the Network Device Class Power Management 1.0
¨ High Performance provided by 100Mbps clock generator and data recovery circuit for 100Mbps receiver

Onboard Flash ROM
¨ Automatic CPU and board configuration
¨ Supports Plug and Play configuration of peripheral devices and expansion cards

Bundled Software
¨
PC-Cillin2000 provides automatic virus protection under Windows 95/98/NT/2000
¨
MediaRing Talk provides PC to PC or PC to Phone internet phone communication
¨
3Deep delivers the precise imagery and displays accurate color in your monitor
¨
WinDVD2000 is a DVD playback application (optional)
¨
Recovery Genius 21st V5.0 provides the function to recover, reserve and transfer hard disk data.
¨
CD Ghost is the software stimulating a real CD-ROM to perform equivalent function.
¨
Language Genius
21st is the software to provides learning tools of language and singing.

Dimensions
¨ Micro ATX form factor (24.4cm x 22cm)
