Sursa in comutatie AC-DC 13.5V 11.2A

Dc voltage: 13.5V
Rated current: 11.2A
Current range: 0 ~ 11.2A
Rated power: 151.2W
Ripple noise (max.): 180mVp-p
Output voltage adj. range: 12 ~ 15V
Voltage tolerance: +/- 1.0%
Line regulation: +/- 0.3%
Load regulation: +/- 0.3%
Setup, rise time: 100ms, 50ms at full load
Hold time (Typ.): 28ms at full load
Voltage range: 88 ~ 132VAC/176 ~ 264VAC selected by switch 248 ~ 370VDC
Frequency range: 47 ~ 63Hz
Efficiency (Typ.): 83%
Ac current (Typ.): 3.2A/115VAC 1.6A/230VAC
Inrush current (Typ.): COLD START 35A
Leakage current: 3.5mA / 240VAC 105 ~ 150% rated output power
Over load: Protection type : Shut down o/p voltage, re-power on to recover
Protenction: 15.53 ~ 18.2V
Over voltage: Protection type : Shut down o/p voltage, re-power on to recover -10 ~ +60 (Refer to output load derating curve)
Wprking temp.: 20 ~ 90% RH non-condensing
Storage temp., humidity: -20 ~ +85, 10 ~ 95% RH
Temp. coefficient: +/- 0.03%/ (0 ~ 50 C)
Vibration: 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Safety standards: UL1012, UL60950-1, TUV EN60950-1Approved
Withstand voltage: I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
Safety isolation resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
Emi conduction radiation: Compliance to EN55022 (CISPR22) ClassB
Emc: Compliance to EN61000-3-2,-3
Harmonic current ems immunity: Compliance to EN61000-4-2,3, 4,5,6,8,11; ENV50204, EN55024, Light indust ry level, criteriaA
Mtbf: 286.7K hrs min. MIL-HDBK-217F (25 )
Dimension: 199*110*50mm(L*W*H)

Mai multe pe site-ul producatorului Mean Well
