SCM Tech 99 - masina gaurit 4 axe

C.N.C. WORKING CENTER (POINT TO POINT) SCM Tech 99 H
Producator: SCM
Tip: Tech 99 H
Anul fabricatiei: 2002
Starea masinii: In functionare
Tipul ofertei: Masina folosita
Date tehnice: C.N.C. WORKING CENTER (POINT TO POINT) with 4 axis (X-Y-Z-C)
- CE mark
- Complete safety enclosure on the working head (Soft Impact Bumpers)
- Goose-neck type machine
- Numerical Control ESA Tria and software XILOG
- Automatic Tool Changing System on the working head (No. 4 storage places for tools)
- Max X axe stroke for vertical electro-spindle (router) mm 3300
- Max Y axe stroke for vertical electro-spindle (router) mm 1340
- Max Y axe stroke for vertical drilling bits mm 1120
- Max Z axe stroke mm 200 (max workpieces/panel passage mm 180)
- Lenght of the working supports/rails mm 1200
- No. 1 Vacuum Pump (100 m3/h capacity)
- No. 14 independent vertical boring spindles (for X and Y axes)
- No. 6 independent horizontal boring spindles (for X and Y axes)
- No. 1 Vertical electro-spindle (router) power HP 9, with access to the Tool change System
- No. 1 Circular saw Unit, rotating 0°-90° by C.N., max diam. mm 200
- Total installed power KW
